1/12 RC Hydraulic Excavator 4200XL 2.0 Version

Want to order please email us

Looking For Agent Across The World!


Special Edition RC Series Hydraulic Excavator Hobbies Exclusive!!!

The Difference Between Man And Boy

1:12 Scale / Full Metal / Ready-to-Run / Battery Powered


Eagle JD series models 1/12 Hydraulic Excavator is the most powerful RC excavator model in production today!Created for the customer who requires reliability and high production in bulk earth moving or construction projects.CNC machined metal parts, fully assembled, ready to dig! Massive power through 380kV brushless system.

Specification:

• 100% CNC machined aluminum (except track and hydraulic pump)

• Flysky 10 channel 2.4Ghz radio

• High Intensity Light (Super bright) (3 Watt)

• Optimized steel hydraulic system

• Scale operator station (can fit a driving figure and seat)

• Steel molded tracks (50mm width, 45 grade carbon steel)

• Efficient under carriage with tracks

• Reliable hydraulic valve and adjustable pump

• Heavy duty hoses (OD 4.5mm Nylon, ID 2.5mm)

• Bearing based undercarriage design

• Undercarriage rotate 360 degrees (endless)

• Powder coated in yellow

• Massive brushless system (hydraulic)

• 125A brushless ESC with BEC

• 380Kv brushless monster torque motor (4130 OutRunner, 6mm shaft)

• Neodymium magnets

• Belt/track is track is controlled individually

• Run time is: 40-50 minutes (6500mAh battery)

• Steel machined oil pump (45mm X 30mm X 15.5mm)

• Digging force: 15kg

• Driving speed: 310 meter per hour

• Scale: 1:12

• Dig depth: 495mm

• Height of cabin: 155mm

• Length: 1.15meter

• Width: 250mm

• Height: 840mm

• Deadweight: 20kg

• Operating oil pressure: 20Bar, 290psi.


What's Include:

A Ready-To-Run 1/12 RC Hydraulic Excavator Machine With Radio Controller,but without battery! Machine will be shipped without oil!


Reference Video On Youtube: http://youtu.be/HbsX1gd1z1c
